Pipes appear to be firm, but these pipes bend due to heat, pressure, and gravity. In this context, expansion joints have a significant role to play. It is better to seek help from a reliable gimbal expansion joints manufacturer so engineers can choose the right components.
Dead weight is the continuous weight produced by the pipeline, the accessories that make it up, the valves, insulation, and whatever material passes through the pipe. Dead weight, when it is not properly controlled, could result in stress on joints and connected apparatus. Good planning in piping involves the use of proper guides, anchors, supports, and flexibility of the pipe.
Various Ways Expansion Compensators Support the Dead Weight of a Pipe
Apart from conveying the fluid or gaseous medium, the pipes have to bear their own weight along with that of other components such as fittings and valves that can be attached to it. The expansion joints assist in dealing with movement.
- Understand what dead weight means
Dead weight involves the constant weight that is experienced from various parts of the pipeline system such as the pipe itself, valves, flanges, fittings, insulating material, and the material inside it. The dead weight is always on the supports irrespective of whether the system is in use or not. Knowledge of the total dead weight is necessary in designing an efficient support system.
- Select the right compensator design
Not every compensator is suitable for all piping systems, as their choice will depend on various parameters such as pipe diameter, temperature, pressure, movements, material, and installation conditions. The gimbal-type compensators enable controlled movements at different angles. In cooperation with the gimbal bellows manufacturer, one should provide comprehensive data on operational conditions and movements.
- Allow thermal movement
The pipes elongate due to heating while contracting due to cooling. In a metallic pipe that is very long, expansion or contraction can be noticeable depending on the change in temperature. Whenever a pipe is not free to move, it experiences stress in the bends, joints, and supports. The compensators for expansion are devices that can help alleviate these stresses.
- Use anchors to control movement
The function of the anchors is to ensure that there is control over how the pipe will be allowed to move. There may be a need for the piping system to expand in a particular direction. It is through the use of the anchors that this can be achieved. Once this is done, the expansion compensator is fitted at the place where the movement will occur. This explains why the placement of the anchors is very important when designing the piping system.
- Consider the weight of insulation and fittings
In estimating dead weight, the weight of the pipe alone needs to be estimated, but also the weight of the insulation, valve, flange, supports, and fittings because all of these contribute to the overall weight. Large valves have significant importance as they can add concentrated load due to their high weight. The complete estimation of the weights helps in getting an accurate idea about the performance of the pipeline.
Conclusion
Expansion joints control thermal movement in pipes and reduce stresses; however, expansion joints do not act as an alternative to pipe supports. The most appropriate way is to integrate pipe supports, anchors, guides, and expansion joints in a systematic manner. It is important to factor in both the dead weight and thermal movement of pipes.
